HOWO Parts
HF7 & HF9 Axle
| No. |
Part No. |
Part Name |
Qty |
| 1 |
AZ9719410083 |
Front axle |
1 |
| 1 |
AZ9125411154 |
Front axle |
1 |
| 1 |
AZ9925410121 |
Front axle |
1 |
| 1 |
AZ9719410093 |
Front axle |
1 |
| 2 |
WG880410031 |
Knuckle pin |
2 |
| 3 |
AZ9112410055 |
Left knuckle |
1 |
| 3 |
AZ9112410056 |
Right knuckle |
1 |
| 4 |
WG880410060 |
Stud |
2 |
| 5 |
WG9100410129 |
Bushing |
2 |
| 6 |
AZ9719410005 |
Steering knuckle Arm |
1 |
|
WG9900410001 |
Steering knuckle Arm |
1 |
| 7 |
190003888626 |
Nut fastener |
2 |
| 8 |
WG9700410049 |
Bearing |
2 |
| 9 |
AZ9719410041 |
Tie Rod Arm(left) |
1 |
| 10 |
AZ9719410040 |
Tie Rod Arm(right) |
1 |
| 11 |
WG880410038 |
Brake shoe pin |
4 |
| 12 |
190003872377 |
Castle Nut |
4 |
| 13 |
Q5005050 |
Cotter pin |
4 |
| 14 |
AZ9100410033 |
Bracket (left) |
1 |
| 15 |
AZ9100410037 |
Bracket (right) |
1 |
| 16 |
WG9100410035 |
Bushing |
2 |
| 17 |
WG9100340017 |
Complex bushing |
4 |
| 18 |
WG880410094 |
Shim |
nB |
| 18 |
1880410095 |
Shim |
nB |
| 18 |
1880410096 |
Shim |
nB |
| 18 |
WG880410097 |
Shim |
nB |
| 18 |
1880410104 |
Shim |
nB |
| 18 |
1880410105 |
Shim |
nB |
| 18 |
1880410106 |
Shim |
nB |
| 18 |
1880410107 |
Shim |
nB |
| 18 |
1880410108 |
Shim |
nB |
| 19 |
WG880410052 |
“O”ring |
2 |
| 20 |
WG880410075 |
Stud |
8 |
| 21 |
190003888458 |
Nut |
8 |
| 22 |
AZ9003963004 |
Grease fitting |
2 |
| 23 |
WG880410059 |
Adjusting bolt |
2 |
| 24 |
Q351B14T15 |
Nut |
2 |
| 25 |
WG9112410009 |
Front hub |
2 |
| 26 |
WG880410100 |
Cap |
2 |
| 27 |
Q43056 |
Spacers |
2 |
| 28 |
WG9100410104 |
Wheel bolt |
20 |
| 29 |
WG9003884160 |
Nut |
20 |
| 30 |
Q150B0816 |
Cap screw |
16 |
| 31 |
Q40308 |
Spring shim |
16 |
| 32 |
190003326543 |
Bearing |
2 |
| 33 |
190003326531 |
Bearing |
2 |
| 34 |
WG99000410114 |
Spacers |
2 |
| 35 |
WG9003074387 |
Seal |
2 |
| 36 |
Q5211016 |
Pin |
2 |
| 37 |
WG9100410062 |
Washer |
2 |
| 38 |
AZ9100411140 |
Knuckle lock nut |
2 |
| 39 |
Q5006370 |
Cotter pin |
2 |
| 40 |
Q151C1220 |
Cap screw |
4 |
| 41 |
WG9100410043 |
Cap |
2 |
| 42 |
WG9100410060 |
Egis Cover |
2 |
| 43 |
WG2297Y4835 |
Plaque |
1 |
| 44 |
WG9112410019 |
Annulus ring |
2 |
